Model

AK6001

AK6008

AK6030

AK6050

AK6180

Chamber size

(WDH)

1㎥±0.1㎥

(1.0×1.0×1.0m)

8㎥±0.5㎥

(2.0×2.0×2.0m)

30㎥±1.5㎥

(3.5×3.5×2.5m)

50㎥±1.5㎥

(4.5×4.5×2.5m)

180㎥±1㎥

Rectangular, or cube shape, Depth(D) is within 85~100% of Width (W)

Rectangular, D<W×2

Test items

(Test sample)

-

Purifying ability, Fine-dust removal efficiency (Polydisperse solid potassium chloride)

Fine-dust reduction durability (ISO 12103-1 A2 particle)

Fine-dust removal ability (Potassium Chloride)

Toxic gas purification ability (Ammonia, toluene, and formaldehyde)

Toxic gas reduction durability (Formaldehyde)

Toxic gas removal efficiency (Ammonia, toluene, formaldehyde, acetic acid, acetaldehyde)

-

-

-

-

Ozone generation concentration

-

Ozone generation concentration

Rated flow volume, fine-dust sensor for air purifier, and noise

Noise

Air tightness

Particle concentration after 20 min is 90% or more of initial concentration for particle size of 0.3 ㎛

Temp./

Humid.

23 ± 3 ℃ (± 1 ℃), 50 ± 10 % R.H ± 5% R.H (average during 20 min)

Temp. 20 ± 5 ℃, atmospheric pressure 760 ± 20 mmHg

Chamber material

Well, ceiling, and floor: uninterruptible panel, STS304, 310, 316 or glass

Surface in chamber: Uninterruptible

Applicable regulations

SPS-KACA002-132;2021, KS C 9304; 10.2,

KS A ISO 1996-2; 8, SPS-C KACA 0027-7269

(According to Client’s requirements, can supply chambers which meet related standard such as GB, AHAM, JEM)

KS C 9326
